VERTICAL MACHINING CENTRE

Specification

  • Make : LMW
  • Work Table : 900 x 430mm
  • X/Y/Z Travel : 800 x 440 x 490mm
  • ATC : 20
  • Table Load Capacity : 600kgs
  • Position Accuracy : ±0.005mm
  • Repeatability : ±0.0025mm
  • Spindle Speed : 6000rpm
  • Control System : FANUC 0i MATE TD
  • Qty : 1 Nos

Specification

  • Make : Hardinge
  • Work Table : 750 x 510mm
  • X/Y/Z Travel : 600 x 510 x 510mm
  • ATC : 20
  • Table Load Capacity : 300kgs
  • Position Accuracy : ±0.005mm
  • Repeatability : ±0.0025mm
  • Spindle Speed : 8000rpm
  • Control System : FANUC
  • Qty : 1 Nos

Specification

  • Make : Maximart
  • Work Table : 385 x 700mm
  • X/Y/Z Travel : 510 x 460 x 500mm
  • ATC : 16
  • Table Load Capacity : 300kgs
  • Position Accuracy : 0.003mm/300mm
  • Repeatability : 0.003mm
  • Spindle Speed : Max 8000rpm
  • Control System : Mitsubishi
  • Qty : 1 Nos

Specification

  • Make : MANFORD-VL-850
  • Work Table : 1000 x 500mm
  • X/Y/Z Travel : 850 x 510 x 560mm
  • ATC : 20
  • Table Load Capacity : 850kgs
  • Position Accuracy : 0.003mm / 300mm
  • Repeatability : 0.003mm
  • Spindle Speed : Max 8000rpm
  • Control System : SIEMENS
  • Qty : 1 Nos

Specification

  • Make : JYOTI-RDX20
  • Work Table : 1000x 530mm
  • X/Y/Z Travel : 820 x 510 x 510mm
  • ATC : 20
  • Table Load Capacity : 400kgs
  • Position Accuracy : 0.01mm / 800mm
  • Repeatability : 0.005mm
  • Spindle Speed : Max 8000rpm
  • Control System : SIEMENS
  • Qty : 3 Nos

Specification

  • Make : COSMOS CVM800
  • Work Table : 1000x 500mm
  • X/Y/Z Travel : 800 x 500 x 500mm
  • ATC : 24
  • Table Load Capacity : 600kgs
  • Position Accuracy : 0.01mm / 800mm
  • Repeatability : 0.003mm
  • Spindle Speed : Max 8000rpm
  • Control System : SIEMENS
  • Qty : 7 Nos

Specification

  • Make : HASS VF2
  • Work Table : 914 x 356mm
  • X/Y/Z Travel : 762 x 406 x 508mm
  • ATC : 20
  • Table Load Capacity : 1361kgs
  • Position Accuracy : 0.01mm / 800mm
  • Repeatability : 0.003mm
  • Spindle Speed : Max 8100rpm
  • Control System : HASS
  • Qty : 1 Nos

CNC TURNING CENTRE

Specification

  • Make : JYOTI DX200-5A
  • Swing bed : 500 MM
  • Max Turning Dia : 350MM
  • Max. Turning Length : 500MM
  • Spindle Power : 7.5Kw
  • No. of Turret : 8
  • Spindle Speed : 4000rpm
  • Control System : FANUC 0i MATE TD
  • Qty : 1 Nos

Specification

  • Make : SMART TURN
  • Swing bed : 480 MM
  • Max. Turning Dia : 200MM
  • Max. Turning Length : 262MM
  • Spindle Power : 7.5Kw
  • No. of Turret : 8
  • Spindle Speed : 4000rpm
  • Control System : FANUC
  • Qty : 1 Nos

Specification

  • Make : JYOTI DX 200
  • Swing bed : 500 MM
  • Max. Turning Dia : 365MM
  • Max. Turning Length : 500MM
  • Spindle Power : 11Kw
  • No. of Turret : 8
  • Spindle Speed : 4000rpm
  • Control System : FANUC
  • Qty : 1 Nos

CNC 2 AXES LATHE VTL-30

Specification

  • Make : ACE
  • Swing Over Bed : 800MM
  • Swing over carriage : 240MM
  • Maximum Turning Dia. : 500MM
  • Maximum Turning Length : 700MM
  • Spindle Power : 28Kw
  • Spindle Speed : 2500 RPM
  • Spindle Speed : 6000rpm
  • Control System : FANUC 0i MATE TD
  • Qty : 1 Nos

TOOL PRESETTER

Specification

  • Make : HAIMER
  • Model : UNO 20140 MICROSET
  • Version : M V 3.4
  • Travel Path :

    Z axis 400 or 700mm
    X axis -50 – 200mm

  • Measuring Range:

    Longitudinal axis 400- 700mm
    Diameter : 400mm
    Repeat Accuracy : +/- 2 μm
    Display Accuracy : 5 μm

  • Tool Dimensions :

    Diameter : 400mm
    Transverse dimension : 220mm
    Max. tool weight : 200kg

  • Qty : 1 Nos
